KPB 81

SKU : 131200

The profile bending machines of the KPB series combine high bending performance with modern mechanical engineering and powerful hydraulics. You can bend medium and heavy steel profiles with great precision. A high drive power and the hydraulically adjustable bending rollers make the entire profile bending machine series a powerful solution for metal construction, locksmithing and general mechanical engineering. These machines are also used in the production of canopies, greenhouses, advertising technology and the furniture industry.

  • All 3 rollers driven
  • Hardened rollers and shafts
  • Hydraulic roller adjustment
  • Allows horizontal and vertical machining
Working area
Shaft Ø 80 mm
Roll Ø 245 mm
Bending speed 4,2 m/min
Driven roll 3 positions
Drive capacity
Motor rating hydraulic pump 5,5 kW
Measures and weights
Overall dimensions (length x width x height) 1,38 m x 1,04 m x 1,54 m
Weight 1600 kg

  • Optimum adaptation to a large variety of profiles using the modular roller system
  • 3 motor-driven rollers
  • Hardened and ground shafts
  • Overload slip-clutch
  • Hydraulic feed of bottom rollers with digital display
  • Hydraulically adjustable straightening rollers; optional
  • Allows horizontal or vertical machining
  • Hydraulic components made by leading manufactures

Digital display SKU:
Digital display
Digital display SKU:
Foot pedal with emergency stop switch
Foot pedal with emergency stop switch SKU:
Control panel
Control panel SKU:
Standard rollers
Standard rollers SKU:
Operating tools
Operating tools SKU:
Operator manual
Operator manual SKU:
