Conventional Vertical Milling Machines

The most popular style of milling machine in the world, the vertical mill, or knee mill, is a versatile machine for industrial applications. Featuring a vertical spindle with a quill, these machines are ideal for single sided milling and drilling. Common table sizes are 230x1250 and 250x1400 and come with a 40 taper spindle. KNUTH includes many standard features on our vertical milling machines including: air powered draw bar, X or X & Y powered axes, DRO and coolant system.

Conventional Vertical Milling Machines

Displaying 1 to 18 of 18 machines

2 Models

Mark Super Series

Multi-side milling/drilling machine with automated feed in the X axis, automated quill feed and tapping unit

Table dimensions: 800x240 mm

Travel X-axis manual / autom.: 560 / 480 mm

SBF 40 TV 1000

Universal milling/drilling machine with automated drilling feed, compound sliding table with driven X axis and swiveling gear head

Table set up area: 730x210 mm

Travel X-axis: 500 mm

MF 1 VP

Vertical milling machine featuring automatic feed on X axis, tilt and swivel head, and pneumatic tool clamping

Table set up area: 1.245x230 mm

Travel X-axis: 760 mm

VHF 1.1

Console milling machine with swiveling milling head, automatic feed in the X-axis, horizontal spindle and swivel table

Table set up area: 1.000x240 mm

Travel X-axis: 535 mm

MF 1 P

Ideal entry level milling machine featuring tilt and swivel head, and pneumatic tool clamping

Table set up area: 1.060x230 mm

Travel X-axis: 670 mm

VHF 2.2

Universal milling machine with swiveling cutter head, automated feed in X and Y axes, horizontal spindle and extensive standard equipment

Table set up area: 1.270x280 mm

Travel X-axis: 700 mm

2 Models

FPK 4.3 • FPK 6.3 Series

Our new generation of machine tools with automated feed and infinitely variable spindle drive

Travel X-axis: 500 mm - 600 mm

Table dimensions: 400x800 mm - 450x850 mm

MF 5 VP

With large traverse paths, automatic feed in the X and Y axes, swiveling milling head and pneumatic tool clamping

Table set up area: 1.370x250 mm

Travel X-axis: 800 mm

UWF 1.2

With universal milling head, automated feed on all axes and swiveling table

Table set up area: 1.370x300 mm

Travel X-axis: 1.000 mm

Servomill® 700

Servo-conventional model with vertical milling head, swiveling top beam and advanced functions

Table set up area: 1.370x300 mm

Travel X-axis: 680 mm

VHF 3

With swiveling vertical milling head, automatic feed in the X and Y axes and motorized table height adjustment, horizontal spindle and swivel table

Table set up area: 1.320x320 mm

Travel X-axis: 1.000 mm

VHF 3.2

With swiveling vertical milling head, automatic servo feed in all axes, horizontal spindle and swivel table

Table set up area: 1.370x320 mm

Travel X-axis: 1.000 mm

UWF 3.2

With universal type milling head, automatic feed on all axis, swiveling table and horizontal spindle

Table set up area: 1.370x320 mm

Travel X-axis: 1.000 mm

UWF 5

Heavy console milling machine with stable SK 50 spindle in the universal milling head, horizontal milling spindle, as well as swivel table and automatic feed in all axes.

Travel X-axis: 750 mm

Table dimensions: 1.325x360 mm
